Outdoor Waterproof Tent 10x10 Outdoor Aluminum Frame Pgoda MarqueeTent For Wedding Events Detailed Specification
quick folding tent
,easy up tent
Outdoor Waterproof Tent 10x10 Outdoor Aluminum Frame Pgoda MarqueeTent For Wedding Events Detailed Specification
| pagoda tent detailed size | ||||
| Item | Width(m) | Length(m) | Side high(m) | Bay space(m) |
| PT3x3m | 3 | 3 | 2.4 | 3 |
| PT 4x4m | 4 | 4 | 2.4 | 4 |
| PT5x5m | 5 | 5 | 2.7 | 5 |
| PT 6x6m | 6 | 6 | 2.7 | 6 |
| PT 8x8m | 8 | 8 | 2.8 | 4 |
| PT10x10m | 10 | 10 | 2.8 | 5 |
| PT 12x12m | 12 | 12 | 3.0 | 6 |
| PT14x14m | 14 | 14 | 3.0 | 7 |
| PT 4x8m | 4 | 8 | 2.7 | 4 |
| PT 5x10m | 5 | 10 | 2.7 | 5 |
| PT6x12m | 6 | 12 | 2.7 | 6 |
| Marquee tent specification | |||||||
| Structure | |||||||
| Aluminum profile | high pressed extrued aluminum alloy 6061-T6,65x65x2.5mm for 3x3m,4x4m, 5x5m | ||||||
| 6x6m, 122x68x3mm for 8x8m,10x10m, 166x88x3mm for 12x12m,14x14m | |||||||
| Steel parts | hot-dipped galvanized , Passed 144 hour of salt spraying test | ||||||
| Raw material | |||||||
| Top roof fabric | 850g/sqm laminate Vinyl, waterproof , fire retardant M2 | ||||||
| UV protection, and Rotproof. Blackout | |||||||
| Side panels | (1) 650g/sqm laminate Vinyl, waterproof , fire retardant M2 | ||||||
| UV protection, and Rotproof. Translucence. | |||||||
| (2) 5cm thickness of sandwitch solid wall, the outer panel is 0.5mm steel. | |||||||
| Stuff all in is fiberglass, heat resistant, and noise resistant. | |||||||
| Option Accessories | |||||||
| Optional Acessories | Grass anchors lining, light, wood flooring, slide glass door and so on. | ||||||
| Loading Specification | |||||||
| Wind loading: | 80km/hour | ||||||
| Snow loading: | 0.3kn/square meter | ||||||
Our pagoda tent detailed structure:
